| Protection Rating | - IP66, NEMA-4X enclosure rating
- Exd II CT6
|
| Material | - SS304 (LTSX04-A, LTSX04-N)
- SS316L (LTSX04-A-L, LTSX04-N-L)
|
| Finish | Stainless steel original color |
| Input Power | 220 V AC, 50/60 Hz |
| Power Consumption | 100 W |
| Pan Range (Movement in Horizontal Plane) | 0° to 360° |
| Pan Speed | 0.1° to 40° per second (fixed speed adjustable) |
| Tilt Range (Movement in Vertical Plane) | -90° to 90° |
| Tilt Speed | 0.1° to 40° per second (fixed speed adjustable) |
| Accuracy | 0.1° |
| Atmospheric Pressure | 80 kPa to 106 kPa |
| Operating Ambient Temperature | -45 °C to 60 °C (-49 °F to 140 °F) |
| Relative Humidity | 5 % to 95 % noncondensing |
| Communication | RS-485 |
| Protocols | Pelco-D, Pelco-P |
| Communication Speed | 1,200/2,400/4,800/9,600/19,200 bps adjustable |
| Standard Setting | - Available with BNC cable (LTSX04-A, LTSX04-A-L)
- RJ45 10/100 base (LTSX04-N, LTSX04-N-L)
|
| Preset | Up to 128 |
| Surge Protection | - |
| Internal Usable Size (Ø × L) | 132 mm × 260 mm (5.2 in × 10.2 in), dual housing |
| Dimensions (W × H × L) | 430 mm × 430 mm × 320 mm (16.9 in × 16.9 in × 12.6 in) |
| Weight | 33 kg (72.8 lb) |
| Window Viewing Area (Ø) | 90 mm (3.5 in) |
| Window Thickness | 10 mm (0.4 in) |
| Number of Outlet Holes | 2 (internal diameter of 14 mm) |
| Outlet Hole Thread Size | G-3/4" × 1 |
