Mã sản phẩm:
Thương hiệu:
– Hỗ trợ quét mã vạch 1D và 2D
– Sử dụng giải pháp chip Impinj E710
– Thiết kế kết cấu tin cậy, tuổi thọ cao, bền bỉ và chịu được va đập khi rơi
– Thiết bị đầu cuối và đầu đọc có thể truyền dữ liệu qua Bluetooth 4.2 hoặc cổng USB
– Cung cấp thư viện liên kết động (DLL) và mã nguồn phần mềm mẫu để hỗ trợ phát triển ứng dụng mở rộng
– Ứng dụng: kiểm kê hàng may mặc, kiểm kê kho bãi, quản lý và kiểm tra tài sản, v.v.
Product Specifications
| RFID Technical Parameters | Data Communication | |||
| Frequency | 902~928MHz（US） 865~868MHz（EU） | Wireless WAN | Dual SIM dual standby | |
| Protocol | ISO18000-6C (standard EPC C1G2) Optional: GB29768, GJB7377.1 | Bluetooth | 4G full network access, backward compatible with 3G, 2G | |
| Chip solution | IMPINJ E710 | WIFI | Bluetooth 4.2+BR/EDR+BLE | |
| Output power | 0-33dbm adjustable | Positioning | 2.4G/5G dual-band, IEEE 802.11a/b/g/n/ac/d/e/h/i/k/r/v | |
| Read speed | >800 pcs/sec | Physical parameters | ||
| Read distance | >18m (depending on the tag) | Overall dimensions | 143.3mmx169mm×90.5mm | |
| Antenna | 4.5dbi | Machine weight | 678g | |
| Function | Read/write | Display screen | 5.7-inch HD (720×1440) | |
| Environmental parameters | Touch screen | Support multi-touch, glove touch, multi-touch, water operation and passive pen signature | ||
| Working temperature | -20 ～ +60℃ | Main battery | 3.85V 9000mAh rechargeable lithium battery | |
| Storage temperature | -40 ～ +70℃ | Charging time | No more than 7 hours | |
| Humidity | 5%RH～95%RH (non-condensing) | Audio | 1.5W speaker, two microphones (supports noise reduction), earpiece, headset | |
| Fall-to-ground shock resistance height | Can withstand the impact of falling from a height of 1.2 meters onto a smooth concrete floor multiple times | button | Volume +, – button, power button, PTT button, 2 scan buttons, handle trigger button | |
| Protection level | IP65 | Camera | 5MP front camera, 13MP rear camera, flash support | |
| Static protection | Air discharge ±15KV, contact discharge ±8KV | sensor | Distance, light sensitivity, acceleration, geomagnetism, gyroscope (optional) | |
| Development Environment | scanning | Professional scanning head, supports scanning mainstream one-dimensional and two-dimensional codes, supports screen scanning | ||
| Operating system | Android 11.0 | Card slot type | Nano-SIM x 2, Micro SD can support up to 128GB expansion | |
| Processor | Octa-core Cortex-A53, 1.4 GHz | |||
| Memory | RAM: 4GB, ROM: 64GB | |||
| Extended memory | Micro SD card, up to 128GB | |||
| Camera | |
| Rear camera | 1300W |
| Front camera | 500W |
| Focus mode | Autofocus, touch selection, face detection |
| Flash | 700mA, flashlight support |
| Video shooting | 1080p front and rear camera video recording |
| Scanning head | |
| Scanning head module | Conventional 2D |
| Rotation angle | 360° |
| Up and down tilt angle | ±45° |
| Left and right offset angle | ±60° |
| Laser type | Class Ⅱ |
| Support code system | UPC/EAN, UPC/EAN with supplementals, Code128, GS1-128, Code 39, Trioptic, Code 32, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, IATA 2 of 5, Industrial 2 of 5,Codabar, Codablock F,MSI,Telepen,Code11, GS1 DataBar variants,PDF417, MicroPDF417, Composite Code,Data Matrix, Maxicode, QR Code, MicroQR, Aztec |
| GPS positioning | |
| Positioning | Positioning parameters |
| Supported modes | Support GPS, A-GPS, Beidou, GLONASS, Galileo |
| Frequency | GPS (L1 1.575GHz C/A code), Beidou (B1 1.561GHz), GLONASS (L1 1.602GHz), Galileo (E1 1.589 GHz / E2 1.561 GHz) |
| Cold start time | Less than 40s |
| Maximum number of channels | 31channel |
| Sensitivity | -130dB (SNR value 40dBHz) |
| Accuracy | 5-10 meters (open space) |
| Wireless communication function | |
| Wifi | Wireless LAN |
| Protocol | IEEE 802.11a/b/g/n/ac/d/e/h/i/k/r/v/w protocols (2.4G/5G dual-band WIFI) |
| Frequency range | 2.4G, 5G |
| Operating channel | CH1~CH13, CH34-CH140, CH149~CH165 (depending on the country (region)) |
| Security | EAP-TLS, EAP-TTLS, PEAP-MSCHAPv2, PEAP-TLS, |
| Roaming | PEAP-GTC, PWD, SIM, AKA, WEP, WPA/WPA2-PSK, WAPI certificate, WAPI-PSK |
| Bluetooth | |
| Standard | Bluetooth parameters |
| Standard Support Mode | BT4.2 + BR/EDR + BLE |
| Connection distance | More than 10 meters |
| Wireless WAN | ||
| Wireless WAN | WAN communication parameters | |
| Communication mode | Dual SIM dual standby | |
|
Domestic version | China Mobile 4G (TD-LTE) China Unicom 4G (FDD-LTE) China Telecom 4G (FDD-LTE) | TD-LTE(B34/B38/B39/B40/B41) FDD-LTE(B1/B2/B3/B4/B5/B7/B8/B12/B17/B19/ B20/B28A/B28B) |
| China Unicom 3G (WCDMA) | WCDMA(B1/B2/B4/B5/B8) TD-SCDMA(B34/B39) CDMA2000 1x EV-DO Rev.A BC0 (800MHz) | |
| China Telecom 3G (CDMA2000) | CDMA1x GSM/EDGE/GPRS(850/900/1800/1900) | |
| Development support | |
| Development support | Parameters |
| Operating system | Android 11.0 |
| Management platform | Supports MDM remote management |
| Support development environment | Eclipse, Android Studio, Vim, Ubuntu |
| System-specific tools | iLuncher main screen tool, system feature settings, scanner settings, cloud intercom |
| Optional accessories | |
| Accessories | Accessory Type |
| Accessories | Charger (supports 1 device + 1 battery), 5-row charger, tempered glass |
